Name: 3.5 Ton Double Drum Road Roller for Asphalt Compaction
Availability: InStock

Features
Specifications
Product Showcase
FAQs
Related Products

Features

Dual Steel Drum System for Uniform Asphalt Compaction

The dual steel drum design with front drum vibration delivers consistent and uniform compaction performance, improving asphalt density and surface finish while reducing the number of passes required in road construction and maintenance projects.

Compact Design for Narrow Jobsite Operation

The 3.5-ton compact structure combined with articulated steering allows flexible operation in confined spaces such as sidewalks, residential roads, municipal maintenance areas, and small-scale infrastructure projects where larger rollers cannot operate efficiently.

Mechanical Drive Rear Wheel Propulsion System

The rear-wheel mechanical drive system paired with gearbox transmission provides a simplified and robust powertrain structure, reducing hydraulic complexity while ensuring reliable traction performance in daily road construction applications.

Integrated Water Spray and Scraper System

Front and rear scraper blades combined with dual-side water spray systems effectively prevent asphalt sticking and improve drum cleanliness, ensuring stable compaction quality and smoother finished road surfaces.

Operator Protection and Comfort Platform

Equipped with ROPS protective canopy, hydraulic steering system, and ergonomic control layout, the machine ensures operator safety and reduces fatigue during long working hours in outdoor construction environments.

Optional Intelligent Water Spray Upgrade System

An optional electronic pressure-controlled water spray system enhances water distribution precision, improving asphalt compaction quality while reducing water consumption in high-standard road construction projects.

Specifications

Operating Mass	kg	3500
Static Linear Load	N/cm	147 / 163
Vibration Frequency	Hz	50
Centrifugal Force	kN	35
Travel Speed	km/h	2.4 / 5 / 7.8
Gradeability	%	20
Turning Radius	mm	4500
Overall Dimension (L×W×H)	mm	2830 × 1420 × 2650
Front Drum Width	mm	1090
Wheelbase	mm	2000
Diesel Power	kW	28
Diesel Model	—	V20-38 C41
Water Tank Capacity	L	200
Steering Angle	°	30
Minimum Ground Clearance	mm	260

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
