Name: 1 Ton Mini Backhoe Loader for Sale with Kohler Engine Option
Availability: InStock

Features
Specifications
Product Showcase
Gallery
FAQs
Related Products

Features

Stable Performance on Uneven Ground

With an optimized wheelbase, tread design, and 250mm ground clearance, the machine maintains stable operation on rough or uneven terrain while still offering strong flexibility in confined working conditions. This improves safety and reliability during field operations.

Efficient & Global-Compliant Engine System

ZT08-12 is powered by a fuel-efficient 37kW diesel engine that delivers stable performance with low fuel consumption, making it ideal for long working hours while reducing daily operating costs. At the same time, the machine supports flexible engine configurations, including internationally recognized brands such as Kohler, as well as EPA and Euro V compliant options. This allows it to meet different emission regulations and adapt to various global market requirements while maintaining reliable performance.

Efficient Loading Capability

With a 0.4m³ front bucket and 2200mm dumping height, the machine enables efficient material loading and smooth transfer to small trucks or trailers, improving on-site handling efficiency.

Smooth and Easy Operation

The torque converter transmission system with a 2F/2R gear configuration provides smooth power delivery and simple forward-reverse operation. This improves driving comfort and reduces operator fatigue during repetitive tasks.

Free Tire Upgrade for Improved Stability & Traction

The standard tire configuration is suitable for everyday operation, while the option to upgrade to a wider tire size at no additional cost helps increase ground contact area. This results in improved stability, better traction, and more balanced load distribution, especially when working on soft or uneven terrain.

Specifications

Overall Dimension（L×W×H）	mm	510013502580
Wheel Base	mm	1910mm
Wheel Tread	mm	1100mm
Min. Ground Clearance	mm	250mm
System Pressure	MPa	16
Operating Weight	Kg	2500
Max. Speed	Km/h	20
Max. Climbing Gradient	°	25
Digging Parameters
Turning Radius	mm	3000
Max. Digging Depth	mm	1500
Max. Digging Dumping Height	mm	1500
Max. Digging Radius	mm	2000
Bucket Width	mm	350
Backhoe Capacity	m³	0.08
Max. Digging Height	mm	2600
Max. Digging Force	kN	25
Rotary Angle Of Excavator	°	180
Loading Parameters
Max. Dumping Height	mm	2200
Max. Dumping Distance	mm	800
Bucket Width	mm	1300
Bucket Capacity	m³	0.4
Max. Loading Lifting Height	mm	3000
Max. Breakout Force	kN	28
Forward Shovel Action Time	S	12
Engnie		Yunnei 490
Rated Power	KW	37
Rated Speed	r/min	2400
Cylinders-Inside Diameter		3-90(4-90)
Gear Shift		F2/ R2
Steering Angle	°	33
Tire Size		825-16
Front Wheel Pressure	kPa	250
Rear Wheel Pressure	kPa	250
Fuel Tank	L	20
Hydraulic Tank	L	20
Drive Type		Four-wheel drive
Variable Speed Type		Hydraulic variable speed
Variable Speed Type	mm	300

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
