1.5 Ton Telescopic Loader
ZT915T
Features
Extended Reach Telescopic Boom for 4.5m Loading Height
The telescopic boom system enables a maximum unloading height of 4500mm, significantly improving stacking efficiency and allowing flexible loading into high-sided trucks and storage areas.
Isuzu-Type Axle for Reliable Heavy Load Performance
The reinforced Isuzu-style drive axle delivers stable torque transmission and strong load-bearing capacity, ensuring smooth power delivery and durability during continuous loading operations on rough and demanding jobsite conditions.
Hydrostatic Transmission System for Smooth Operation
The 240 full hydraulic torque converter system provides smooth power delivery and improved control, ensuring stable performance during frequent start-stop and precision loading operations.
Quick-Attach Hydraulic System for Multi-Tool Applications
Equipped with a hydraulic quick-change device and four-way valve system, the machine supports fast attachment switching, improving versatility across different jobsite tasks.
Heavy-Duty 4WD Chassis for Stable Terrain Performance
The four-wheel drive system combined with reinforced axle structure ensures strong traction and stability on uneven ground, improving operational reliability in farmland and rough jobsite conditions.
Operator Comfort Cab with Full Safety Configuration
The fully equipped cab includes suspension seat, adjustable controls, LED lighting, rear camera, emergency tools, and heating system, improving comfort and safety during long-hour operation in all weather conditions.
Specifications
| Rated load | kg | 1500 |
| Engnie | Yunnei YN27GB | |
| Rated Power | KW | 42 |
| Overall Length | mm | 5800 |
| Overall Width | mm | 1800 |
| Overall Height | mm | 2680 |
| Max. Discharge height | mm | 4500 |
| Min. Discharge height | mm | 3500 |
| Bucket Capacity | m³ | 0.65 |
| Bucket Type | Heavy-duty bolt on teeth | |
| Max. Load | 1500 including bucket or attachment | |
| Steering System | Articulated hydraulic steering | |
| Driving System | Four wheel drive | |
| Service Brake | Four wheel disc brake | |
| Parking Brake | Disc brake | |
| Tire Model | 20.5/70-16 | |
| Wheel base | mm | 2500 |
| Wheel Track | mm | 1500 |
| System pressure | Mpa | 16 |
| Weight | kg | 4200 |
