Name: 2.5 Ton Backhoe Front Loader with Cummins Engine Options
Availability: InStock

Features
Specifications
Product Showcase
Gallery
FAQs
Related Products

Features

Flexible Engine Options for Different Markets & Regulations

Powered by a reliable 75kW turbocharged engine from Yuchai, the system also supports optional Cummins and Euro V Yuchai engines, allowing better compliance, cost control, and performance matching for different working regions.

Semi-Electronic Transmission for Balanced Control & Efficiency

The semi-electronic 4F/4R transmission system improves gear transition smoothness while maintaining mechanical reliability, allowing more stable performance during frequent switching between digging and loading operations. This balanced design improves operational efficiency while keeping the system robust and easy to maintain in long-term field use.

Certified ROPS Cab for Structural Safety

The ROPS-certified cab helps maintain a protected operator space during rollover risks, improving safety in extreme working conditions. Its reinforced structure also enhances overall cab rigidity, reducing vibration and improving stability during rough terrain operation.

Strong Working Force for Real Heavy-Duty Applications

ZT388H-Ⅱ delivers high-performance digging and loading capability with a 46kN breakout force and 72kN loading penetration force, ensuring stable performance when handling hard soil, gravel, and compact materials. This provides consistent working power even in demanding construction and earthmoving conditions.

All-Terrain Capability for Tough Working Conditions

A 35° climbing ability combined with a high ground clearance design enables stable operation on slopes, uneven ground, and rough job sites. The full-time four-wheel drive system further enhances traction, ensuring reliable movement in muddy, sandy, or unstable terrain conditions.

High Mobility for Fast Job Site Transfer

With a maximum travel speed of 38 km/h, the machine significantly reduces relocation time between job sites, making it highly efficient for rental fleets, municipal operations, and multi-site contractors. This improves overall productivity by minimizing non-working travel time.

Extended Working Endurance for Long Shifts

Equipped with 150L fuel and hydraulic oil tanks, the machine supports extended working hours without frequent refueling, improving uptime in long-duration construction projects.

Specifications

Overall Dimensions	Dimensions (mm)	650025003800
	Wheelbase (mm)	2250
	Track Gauge (mm)	2050
	Minimum Ground Clearance (mm)	400
	Minimum Turning Radius (mm)	4200
Performance Parameters	System Pressure (Mpa)	18
	Total Machine Weight (kg)	9200/9600
	Maximum Speed (Km/h)	38
	Maximum Climbing Ability(°)	35
Excavation Parameters	Maximum Telescopic Excavation Depth (mm)	4000/5300
	Maximum Excavation Radius (mm)	5700/6500
	Maximum Lifting Height (mm)	5800/6300
	Bucket Capacity (m³)	0.3
	Maximum Excavation Force (KN)	46
	Excavator Rotation Angle (°)	190
	Maximum Bucket Excavation Radius (mm)	900
Loading Parameters	Maximum Unloading Height (mm)	2800
	Maximum Unloading Distance (mm)	800
	Bucket Capacity (m³)	1.2
	Penetration Force (KN)	72
Engine	Model	Yuchai
	Type	Turbocharged
	Rated Power (KW)	75
	Rated Speed (r/min)	2200
	Number of Cylinders - Bore	4-108
Transmission System	Transmission	Semi-Electronic Shift Transmission
	Number of Gears	4 Forward, 4 Reverse
	Hydrostatic Torque Converter	Beilian YJ315K-II
Axle	Brand	30 Drive Axle
Tires		16.9-28
	Driving Brake	Air Over Hydraulic Disc Brake
	Parking Brake	Hand Brake
Oil Capacity	Fuel Tank (L)	150
Oil Capacity	Hydraulic Oil Tank (L)	150
Others	Drive Type	Four-wheel Drive
	Transmission Type	Hydraulic Variable Speed Driver
	Control System	Electromagnetic Hydraulic Pilot Control

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
