3 Ton Wheel Loader
ZT930
Features
High Capacity & Expandable Bucket System
Standard 1.6m³ bucket, expandable up to 2.0m³, with reinforced tooth bucket design for stronger penetration and higher loading efficiency.
Reinforced Heavy-Duty Structure
5cm reinforced front frame + heavy-duty chassis + 35mm boom thickness provide exceptional structural strength and durability for continuous heavy-load operations.
Multi-Function One Machine Solution
ZT930 supports multiple quick-change attachments including bucket, pallet fork, grapple, wood fork, grass fork, auger, breaker, snow blade, and 4-in-1 / 6-in-1 bucket systems, enabling one machine to perform multiple jobs efficiently.
Heavy-Duty Split Transmission System
The Jinlite 315 split transmission is designed for heavy-duty loading operations, providing stable power transfer and improved durability under continuous working conditions. The split structure allows easier maintenance and better heat dissipation, ensuring reliable performance in construction and material handling applications.
Specifications
| Rated Load | kg | 3000 |
| Bucket Width | mm | 2300 |
| Bucket Capacity | m³ | 1.6 |
| Overall Dimension | mm | 7000*2300*3060 |
| Operating Weight | kg | 8000 |
| Max. Dumping Height | mm | 3800 |
| Max. Dumping Distance | mm | 1050 |
| Wheel Base | mm | 2770 |
| Wheel Tread | mm | 1690 |
| Engine | Weichai | |
| Rated Power | kw | 92 |
| Rated Speed | r/min | 2200 |
| Tire Size | 17.5-25 |
Product Showcase
Why Choose TDER?
20+ Years of Expertise
158 Countries Served
42,000㎡ of Advanced Production
Over $91M+ Annual Sales
