5 Ton Wheel Loader
ZT956
Features
Meritor Heavy-Duty Axle System
The ZT956 is equipped with a Meritor heavy-duty axle system, a globally recognized premium brand widely used in international construction and commercial vehicles. It delivers exceptional load-bearing capacity, superior traction performance, and excellent durability under continuous heavy-duty working conditions, ensuring stable and reliable operation in demanding applications.
Planetary Power Shift Transmission System for Uninterrupted Power Delivery
The planetary power shift transmission system enables smooth and uninterrupted gear shifting without power interruption, allowing the loader to maintain continuous pushing, loading, and material handling operations under heavy-duty conditions. This system improves torque multiplication efficiency and ensures stable power delivery during frequent load changes, significantly enhancing overall working productivity.
Smooth & Precise Operating Experience
Equipped with pilot control system and Eaton steering components, ZT956 provides smoother hydraulic response, lighter operation feel, and improved control precision, significantly reducing operator fatigue during long working hours.
Strong Continuous Working Performance
ZT956 is designed for high-intensity and long-duration loading operations. With a 162kW Weichai WD10G220E21 engine and optimized powertrain matching, the machine delivers stable torque output and consistent performance under heavy and continuous workloads, ensuring high productivity in demanding job cycles.
Stronger Load Efficiency & Simplified Structure
The single boom design in ZT956 provides a more rigid structural layout with fewer articulation points, resulting in improved lifting force concentration, better load transfer efficiency, and enhanced durability during continuous heavy-duty operations. This structure also simplifies maintenance and improves long-term structural stability under high load stress conditions.
Specifications
| Rated Load | kg | 5000 |
| Bucket Capacity | m³ | 3 |
| Overall Dimension | mm | 8620*2980*3380 |
| Operating Weight | kg | 18050 |
| Wheel Base | mm | 3300 |
| Wheel Tread | mm | 2150 |
| Engine | WeiChai | |
| Rated Power | kw | 162 |
| Rated Speed | r/min | 2000 |
Product Showcase
Why Choose TDER?
20+ Years of Expertise
158 Countries Served
42,000㎡ of Advanced Production
Over $91M+ Annual Sales
